PRO Samurai series - 15" High Efficiency Subwoofer. (3500 W).

Super Power !

PRO Samurai series TS-W3820PRO subwoofer has a nominal power 1800 W and double coil with impedance 2 + 2 ohms. The wide stitched-reinforced urethane surround provides long cone stroke and a secure fit at high volumes. The 4-layer copper-clad aluminum voice coil allows to achieve weight reduction and high sensitivity. The high quality aluminum basket construction dissipates heat away from the voice coil. Big double magnet provides high power.

Specifications

Samurai
SamuraiThe Samurai series of loud speakers is designed to build loud systems with high sound pressure. They are represented by two subwoofers, 30 and 38 cm, which are able to work with high volume levels and provide deep bass.
PRO Pioneer Reference for Open Show
PRO Pioneer Reference for Open ShowThe Pioneer Reference Series for Open Show is designed specifically for those looking to produce some serious sound pressure levels.
View all specifications

Full specifications

Main Features

Samurai
PRO Pioneer Reference for Open Show
Size 30 cm
Type Subwoofer
Maximum power 3500 W
Continuous Power Output 1800 W
Frequency response 20 Hz to 200 Hz (In-Car)
Sensitivity 88 (1 W/In-car) dB
Impedance 1 Ω or 4 Ω
Dual Voice Coil (DVC)
Mounting Depth 154 mm
Woofer Cut-Out Hole Φ352 mm
Woofer material Paper
Surround Urethane
Spider Polyester Fibre
Voice Coil type 4-layer Long Copper
Voice Coil bobbin type Aluminium
Terminals Push
Magnets Ferrite
38cm / 15"
Recom. Enclosure [l] 57 (Sealed Enclosure)
90 (Ported Enclosure)
Recom. Enclosure [ft3] 2.01 (Sealed Enclosure)
3.18 (Ported Enclosure)
Weight 11.7 (Excluding accessories) kg
Dimensions Φ405 x 216 mm
Accessories Subwoofer mounting screws

Thiele/Small Parameters

Qts 0.8
Fs [Hz] 27.1 Hz
Vas [ft3] 2.69
Vas [l] 76.20
Xmax [mm] 22.8
